Square main drains for pools.

Grille 175×175. Connection 2″.

MAIN DRAIN SQUARE

WAKINGLIGHTING

PAR56 Glass
Power Options: 300w
Body Material: ABS+UV
Dimensions: Ф177.8mm

SPARE BULB PAR56 HALOGEN

ROBUST STEEL ARMS OF POOLS
Ladder handrails are made of φ42mm tubes in polished stainless steel 304 (or 316 for saltwater pools). Correct selection and proper placement of handrails and ladders add a significant measure of safety to every pool area. Three kinds of step are available: Plastic, stainless steel, and stainless steel with anti-slip pads. All ladders are available with anchor or flange type fixtures for easy installation.

Product Features
Handrails is made from polished Stainless Steel 304 or 316(Ф42mm) tube
Steps available in stainless steel and plastic
Complete with anchoring fixtures or flange fixtures

EXIT HANDRAIL ARN

OZONE ADAPTAR 55 WATT

102mm Stainless Steel Wall Mounted Pool Light
Power Options: 5W
Body Material: SS316
Dimensions: Ф102 x 15 mm
Waterproof Way: Resin filled
Waterproof Level: IP68
Model: HJ-WM-SS102

FLAT LIGHT WAKING 5W

6 LPH @ 4 bar Pressure
Infinity positive displacement diaphragm metering pump operating at 230V, 50Hz supply.
It is base mountable. Solenoid push the diaphragm which in turn pushes the liquid into the system.
Solenoid is actuated by a solid state electronic circuit. It has controls for the desire accuracy of the dosing. Dosing rate @ 4 kg/cm²: 6.0 LPH (IDP 6)
Suction/Discharge tubing: 4/6 mm
Frequency: Up to 400 SPM
Electrical: 230V AC, 50 Hz
Power Consumption: 30 Watts
Fuse: 500mA / 230V AC
Pump Stroke per minute: 120 Max ( Adjustable)
Negative Suction: 1 Mtr
Environment Temperature: 40°C Max
Head: HDPE
Diaphragm: Teflon (PTFE)

DOSING PUMP INFINITY 5L/8BAR

The Main Drain is designed to prevent groundwater from intruding the pool. Main and Gutter are constructed with injection molded ABS and PVC while featuring a dome-shaped cover. It can be mounted on the floor of both concrete and vinyl pool.

FRAME AND GRATE

An ozone generator is a device used to produce ozone gas (O3). Ozone is easy to decompose and cannot be stored, and needs to be prepared on site for on-site use, so ozone generators and ozone generator modules are used in all places where ozone can be used.

OZONE GENERATOR

Mouth bottom made of ABS material.

The upper part of the mouth has a flat shape.

Spout adjustment base up to 12° inclination. Adjustable supply.

Suitable for concrete pools.

FLOOR INLET 63mm Adjusustable

Aqua

AQUA HC997 is multifunction solenoid driven dosing pump with constant and proportional dosing with push buttons interface and digital LCD display for programming.


General Specifications:

LCD Display with Backlight
5 pushbutton interface
Constant Mode: flow rate, time, quantity, cyclic
Proportional Mode: 4-20mA input, pulse input, PPM
Time Mode: Daily or Weekly
Alarm: Level & Flow
Relay output
Maximum Flow 14 l/hr @ 0 bar
Maximum Pressure 20 bar @ 2 l/hr
Tube Connection Size 4mm x 6mm
Power Supply 230VAC
ON / OFF Switch
Level Input (pump interlock)
Wall & Bench Mounting Kit
IP65 Rating
Wetted Parts:

Pump Head PVDF
Ball Valves PTFE
Valve Body PVDF
Fittings PVDF
Injection Valve PVDF, Hastelloy, PTFE
Foot Valve PVDF
Seals Viton or EPDM
