Self-priming centrifugal electric pump for swimming pools. Self-priming at 2 m.
Built-in pre-filter of great capacity (8 litres).
Pre-filter with transparent lid in polycarbonate which allows easy observation of the pre-filter basket. The pre-filter is closed with a knob system of easy accessibility.
Pump body made in polypropylene reinforced with fibreglass, resistant to the chemical products in the swimming pool, guaranteed to last a long time.
Mechanical seal in graphite and ceramics.
Motor shaft manufactured in stainless steel AISI 316L.
Motor with IP-55 protection, at 2.850 r.p.m. Tension of mains feed at 230/400V-50Hz three-phase (Ask for 400/690V-50Hz versions).
Possibility of IE2 Efficiency Motors upon request
Possibility of 60Hz upon request.
Versions of 3HP, 4HP and 5,5HP.
Suction connection Ø90 mm, return connection Ø75 mm. Both supplied with bush connections.

SWIMMING POOL PUMP IML 4HP DY SERIES

ROBUST STEEL ARMS OF POOLS
Ladder handrails are made of φ42mm tubes in polished stainless steel 304 (or 316 for saltwater pools). Correct selection and proper placement of handrails and ladders add a significant measure of safety to every pool area. Three kinds of step are available: Plastic, stainless steel, and stainless steel with anti-slip pads. All ladders are available with anchor or flange type fixtures for easy installation.

Product Features
Handrails is made from polished Stainless Steel 304 or 316(Ф42mm) tube
Steps available in stainless steel and plastic
Complete with anchoring fixtures or flange fixtures

EXIT HANDRAIL ARB

ROBUST STEEL ARMS OF POOLS
Ladder handrails are made of φ42mm tubes in polished stainless steel 304 . Correct selection and proper placement of handrails and ladders add a significant measure of safety to every pool area. Three kinds of step are available: Plastic, stainless steel, and stainless steel with anti-slip pads. All ladders are available with anchor or flange type fixtures for easy installation.

Product Features
Handrails is made from polished Stainless Steel 304 (Ф42mm) tube
Steps available in stainless steel and plastic
Complete with anchoring fixtures or flange fixtures

OVER FLOW LADDER EMAUX

WAKINGLIGHTING

PAR56 Pool Light Bulb Glass
Power Options: 12W/18W/25W
Cover Material: Anti-glare PC
Dimensions: Ф177.8 x 92 mm
Waterproof Way: Structural waterproofing
Waterproof Level: IP68

SPARE BULB PAR56 LED

Pool China

10/26CM STAINLESS  BRISTLE WALL BRUSH
VACUUM HEAD are made of robust PA / Aluminium materials. These models are designed for heavy-duty use and have a strengthened handle and flexible wheels

STAINLESS STEEL ALGAE BRUSH

Highly resustant abs material.
Flat shape for inlets top part.
Flow rate 12m3/h (63mm) or 6m3/h (50mm).
Design for concrete swimming pools.
UV protection.
Color:Black

VACCUM INLET 63 BLACK

PROVEN LONG-TERM DURABILITY
The SB Series pump delivers high flow and energy efficiency ultra performance. 2-inch suction and discharge port with a transparent lid. Ring lock seal design to eliminate suction leaks and to maximize suction efficiency.

Product Features
2 inch suction and discharge ports
Ring-lock lid eliminates leaks andmaximizes suction efficiency
Asynchronous, two-pole motor
 Class insulation: 130(B)
IPX5 Waterproof standard
Built-in thermal protection
Overload protection
Available in 50Hz or 60Hz for 220V/380V
Specially designed unions compatible for both Imperial and Metric standards
Testing Pressure (50PSI / 3.5Bar)
316 stainless steel shaft
316 stainless steel mechanical seal

SWIMMING POOL PUMP EMAUX SB SERIES

The Suction Fitting and Vacuum are designed for concrete, vinyl and fiberglass pools. They are manufactured from ABS and PVC plastic by injection moulding.The high quality of materials and the rigorous controls of production processes guarantee a long life for our equipment.

VACUUM INLET 63-2"

Aqua

The Etatron AP range of piston dosing pumps are designed for applications requiring larger precise flow rates up to 190L/hr and higher pressures up to 20 bar. This range is not suitable for use with liquids containing abrasive or solid particles. This metering pump series can be controlled in various ways depending on application requirements, including; 4-20 mA signal and inverter control.



The metering pump head is available in either PVC, PVDF or stainless steel AISI 316 depending on the nature of the fluid. Seal materials options include; NBR, FPM and EPDM. This combination of materials options make this pump range suitable for a wide range of fluids and applications.



This dosing piston pump series is ideal for many applications in the industrial and marine markets, including; chemical dosing for maintaining PH levels in water treatment processes, Legionella dosing, biocides,  OEM dosing systems, reverse osmosis, chemical injection and chemical dosing for agriculture.





Product Summary



•                      Etatron AP series piston metering pump

•                      Larger precise flow rates up to 190 L/hr

•                      Discharge pressures up to 20 bar

•                      10% to 100% stroke length adjustment

•                      Pump head available in  PVC, PVDF  or stainless steel AISI 316

•                      Seals available in NBR, FPM or EPDM

•                      Fitted with either single or double ceramic ball valves

•                      4-20 mA control possible with optional servo motor mechanism

•                      Level control supported

•                      Can handle fluids with viscosities up to 2000cp

•                      Self-priming

•                      120 strokes per minute maximum

•                      Aluminium casing with epoxy/acid proof coating

•                      IP55 motor protection

•                      Single phase 230V, 110V or three phase 230/400V 50/60Hz motors available

•                      Available with Atex motor for installation in non-safe areas

•                      Available with motors suitable for operation via external inverter (variable frequency drive VFD)

DOSING PUMP AQUA PH W/O PROB

Ultrathin LED Fountain lights, Ultrathin LED Pool Lights, led pool lights, led pond lights, led spa lights,led slim pool light,slim led pool light

Dimension: D100mm*H8mm

Specification:

Material:PC

Light color: green,blue,red,yellow,white,RGB

Voltage: DC12V

Watt: 10W 800LM

Color Temperature:2700k-6500k

LED Chip: SamSung Brand

Waterproof grade: IP68

Beam angle: 120°

Working environment temperature: -25°C~45°C

Control method: Inbuilt driver

Working Lifetime 50,000 hrs

Advantage:

1) Install easily ONLY with 2 screws

2)  Ultra-flat only 8mm slim.

3) Replacing and install by 3 minute(much down the maintain cost)

4) Never don't worry water leaking

5) High brightness LED

6) Available DMX signal
